Facility Type:
Public areas exposed to vandalism. Parking Garages, School Gyms
Confirm with local building codes or authority having jurisdiction regarding restrictions on locked fire protection cabinets
Standard Product Specifications:
14 Ga. FULL METAL Painted Adjustable Fronts with 1/2" return trim - Grey
18 Ga. Painted Tubs - White
Hinges: Standard Piano Hinges
Lock: Model 151 Standard Cylinder Lock
OPTIONS: Minimum Security Cabinet
Paint Options: Red, White, Yellow, Black
Handle: "D" chrome pull handle
Front: Breakglass lock round opening & pull lever for emergency access.
Front Material: 304 Stainless with No. 4 Satin Finish
Cabinet Identification: Die Cut Decals (Red or White) "Fire Extinguisher", "Fire Hose" or "Fire Dept. Valve"
| Model | Tub Size W H D | Frame O.D. | Extinguisher Type |
| 102RS-MIN | 8" x 17" x 5" | 12" x 21" | 5 lbs Dry Chemical |
| CE-950-3-MIN | 9"x 24"x 6" | 13" x 28" | 10 lbs. Dry Chemical |
| CE-950-3-2-MIN* | 9"x 24"x 6" | 13" x 28" | 10 lbs. Dry Chemical |
| CE-950-2-MIN | 10" x 30" x 8" | 14" x 34" | 10 lbs. CO2 |
* CE-950-3-2-MIN comes with a 2" turn back on frame in order to accomodate 4" wall depth.
