Facility Type:
Federal, Provincial & State maximum security institutions where fire fighting equipment is stored within inmate or prisoner areas.
Standard Product Specifications:
10 ga. FULL METAL Adjustable Fronts. Reinforced door, 1/4" return on door - Grey powder coated paint.
10 ga. painted Tubs - Grey
Hinges: Model 850T Security Hinge
Lock: Model 7010 High Security Mechanical Deadbolt Lock.
Lock: Fire Extinguisher Cabinets use Model 7017 compact security lock.
OPTIONS: Maximum Security Cabinet:
Paint Options: Red, White, Yellow, Black
Handle: Model H2856P loop pull handle (required with padlock installation)
Door Pull: Model 3000011 flush mounted handle (required with padlock installation)
Hinges: H2301D Heavy Duty Security Hinges
Lock: Padlock Door Hasp
Cabinet Identification: Die Cut Decals (Red or White) Fire Extinguisher, Fire Hose, Fire Dept. Valve
Model | Tub Size | Frame O.D. | Extinguisher Type |
CE-950-3-MAX | 9"x24"x7 1/2" | 13" x 28" | 10 lbs. Dry Chemical |
CE-950-2-MAX | 10"x30"x9 1/2" | 14" x 34" | 10 lbs. CO2 |
Confirm with local building codes or authority having jurisdiction regarding restrictions on locked fire protection cabinets
